Heidolph, Magentic Stirrer, MR Hei-Standard
SKU: HEI-STANDARD
Price RangeCall for Quote
Description
According to the motto “just stir and heat”, our entry model of the Hei-Standard was manufactured with two rotary knobs to enable direct access to the two main functions. The speed and temperature are set using a scale. The maximum values are 1.400 rpm and 300 °C.
This magnetic stirrer is very easy to use and is equipped with the most important safety features. The heating function can be activated separately.
The patented Kera-Disk® footprint made of anodized aluminum, is chemical-resistant, scratch-proof, and has a diameter of 135 or 145 mm. This unique size makes it suitable for use with many accessories and samples on a small footprint. The material used also enables the fastest heating times.
Rotation speed range | 100 – 1,400 rpm | 100 – 1,400 rpm |
---|---|---|
Speed accuracy | ±2 % | ±2 % |
Max. stirring capacity (H₂O) | 20 l | 20 l |
Hotplate temperature | 20 – 300 °C | 20 – 300 °C |
Heating power | 600 W | 600 W |
Accuracy temperature setting | ±5 °C | ±5 °C |
Temperature accuracy with external temp. sensor | ±1 °C | ±1 °C |
Safety circuit hotplate | 25 °C over hotplate temperature | 25 °C over hotplate temperature |
Plate diameter ø | 135 mm | 145 mm |
Plate material | Kera-Disk® (Silumin with ceramic coating) | Kera-Disk® (Silumin with ceramic coating) |
Sensor breakage protection | with Pt 1000 | with Pt 1000 |
Residual heat indicator | yes | yes |
Smooth start | yes | yes |
Analog / digital interface | – | – |
Timer | – | – |
Protection class DIN EN 60529 | IP 32 | IP 32 |
Heidolph Product Number | 036110521 | 036110519 |
Name | SKU | Price | Buy |
---|---|---|---|
Heidolph, Magentic Stirrer, MR Hei-Standard - Plate Diameter: 135 mm, Heidolph Part Number: 036110521 | HEI-036110521 | Call for Quote | |
Heidolph, Magentic Stirrer, MR Hei-Standard - Plate Diameter: 145 mm, Heidolph Part Number: 036110519 | HEI-036110519 | $1,224.09 |
