Price Range$495.00 – $605.00
Description
- Computer controllable: networkable up to 100 pumps
- Stand-alone operation: pre-program the pump with a dispensing program, then operate the pump from an attached Foot Switch, button, or I/O controller
- Add the OEM Starter Kit to run as a fully functional, stand-alone pump
- Does not have a built-in user interface
- Chassis mountable: 9 1/2″L x 4″W x 4 1/8″H (24.13 x 10.16 x 10.5 cm)
If chassis does not fit in your system, we make custom designed OEM syringe pumps to accommodate your specific needs.
- Operates from a 12V DC power source
- Holds 1 syringe up to 60 mL. 140 mL with long chassis.
- Infusion rates from 0.73 µL/hr (1 mL syringe) to 2100 mL/hr (60 mL syringe)
- Fully programmable and automation capable
- Operates stand-alone or from a computer
- Infusion and withdrawal
- Available in High Pressure, Stall Detection & Long Chassis options.
- Set a single pumping rate and/or dispensing volume
- Program up to 41 pumping phases that change pumping rates, set dispensing volumes, insert pauses, control and respond to external signals, extra I/O expansion port, sound the buzzer
- Network, control, and monitor up to 100 pumps with one computer
- Dispensing accuracy of ± 1%
- Unlimited lifetime technical support
- Two year warranty
- Disposable, Glass, Stainless Steel Syringes and Plumbing Supplies are sold separately
- Download our free pump terminal emulator or get a trial version of our Windows based SyringePumpPro
- Custom modifications to the mechanics and firmware are also available
|
| Syringe Size |
Maximum Rate |
Minimum Rate |
| 0.5 µL |
25.49 µL/hr |
0.001 µL/hr |
| 1 mL |
52.86 mL/hr |
0.727 µL/hr |
| 3 mL |
223.8 mL/hr |
3.076 µL/hr |
| 5 mL |
372.5 mL/hr |
5.119 µL/hr |
| 10 mL |
607.6 mL/hr |
8.349 µL/hr |
| 20 mL |
966.2 mL/hr |
13.28 µL/hr |
| 30 mL |
1260 mL/hr |
17.32 µL/hr |
| 60 mL |
2120 mL/hr |
29.1 µL/hr |
| 140 mL |
3470 mL/hr |
47.7 µL/hr |
|
|
| Model |
Standard |
High
Pressure |
Stall
Detection |
Long
Chassis |
| P-NE-500 |
X |
|
|
|
| P-NE-501 |
X |
|
X |
|
| P-NE-510 |
|
X |
|
|
| P-NE-511 |
|
X |
X |
|
| P-NE-500L |
X |
|
|
X |
| P-NE-501L |
X |
|
X |
X |
| P-NE-510L |
|
X |
|
X |
| P-NE-511L |
|
X |
X |
X |
|
|
