Caframo Lab Solutions®, Overhead Stirrer, Compact Digital, 100-240 Volt, Model CLS-BDC2002

SKU: CLS-BDC2002

Price Range$1,213.00

Description

Caframo’s BDC2002 offers ultimate versatility and maximizes productivity. With the push of a button, the unique Stirlight™ lights up so that solutions can be seen clearly. Included in each purchase: Overhead stirrer motor, chuck, chuck key, support rod, external power supply, grounded power cord, manual in four languages (English, French, Spanish and German) and three year warranty.

Speed 40-2002 rpm
Volume Maximum 25 L (6.5 US Gallons)
Viscosity Maximum 15 000 mPa·s (15 000 cps)
Torque Maximum 70 N·cm (6 in-lbs = 100 in-oz)
Output Power 40 Watts (1/18 hp)
Speed Display Yes
Speed Accuracy /- 1 rpm
Torque Display No
Zero Torque No
Timer No
Through Shaft Yes
Chuck Maximum Shaft Diameter 9.5 mm (⅜”)
Chuck Guard Available
Rotation Direction Clockwise only
Housing Epoxy-coated zinc
Weight Power Supply: 0.5 kg (1 lb), Stirrer: 3.0 kg (7 lb)
IP Rating IP42
Voltage 120 volt/230 volt
Frequency 50/60 Hz
Ambient Temperature Operation 5-40°C (41-104°F)
Relative Humidity Operation 80%
Approvals – North America CAN/CSA-22.2 Std No. 61010-1 & 61010-2-051 3rd Ed., UL/ANSI Std No. 61010-1 3rd Ed.
Approvals – Europe EN 61326-1: 2013, Europe CE, IEC 61010-1 & 61010-2 3rd Ed.
Warranty 3 years

Overhead stirrer motor 100-240 volts, 50/60 Hz. Includes support rod, chuck, chuck key, external power supply, grounded North American power cord, and printed manual.

Remember to order a stand, clamp and impeller for a complete system to start mixing.

  • Features
    • Stirlight™
    • Sealed housing
    • Brushless DC motor
    • Digital display
    • Through shaft
    • Auto Start
    • Electronic digital control
  • Benefits
    • Allows monitoring of mixing properties of batches
    • Keeps liquids and moisture out in aggressive environments
    • High efficiency (less heat)
    • Precise speed adjustment
    • Easy impeller adjustment saves time
    • Resumes stirring at last set speed automatically when power is restored
    • Set speed is maintained as viscosity changes
    • Automatic overload protection
