Julabo, Refrigerated Circulator, CORIO™ CP-1001F
SKU: JB-CP-1001F
Price Range$15,358.00
Description
CORIO™ CP refrigerated/heating circulators are suitable for temperature applications with circulation to an external apparatus or immersing a device in the bath tank. Refrigeration combinations offer low temperatures between -20 °C to -50 °C with an upper limit of 200 °C. The CORIO™ CP circulator incorporates easy change-over for control of fluid circulation internally or externally. Unit fittings M16x1 male threaded adapters including a pair of 8 and 12 mm hose barbs.
USB and RS232 connections for external PC control and data-logging. A space-saving cooling coil design yields more usable space in the bath tank. Bath lid and drain tap included.
PID temperature control provides ±0.03 °C stability. Adjustable centrifugal pump capacity of 8…27 L/min with pressures 1.5…10.2 psi.
Stainless steel bath tank. Class III (FL) according to DIN 12876-1
Included with each unit: 2 each barbed fitting for tubing 8 and 12 mm inner dia. (pump connections M16x1 male)
- Models for internal and external applications
- Bright, white, easy to read display
- Very quiet
- Easy pump change-over (internal and external circulation)
- External pump connections (M16x1)
- USB & RS232 connection
- Space-saving cooling coil design yields more usable space in the bath tank
- Bath lid and drain tap included
- Removable ventilation grid
- Refrigeration unit without side vents
- Class III (FL) according to DIN 12876-1
Specs-At-A-Glance
Cooling Capacity |
|
||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Heating Capacity (kW) | 2 @ 230 V | ||||||||||||||
Cooling Capacity | 0.13 kW @ -30 °C, 0.35 kW @ -20 °C, 0.6 kW @ -10 °C, 0.9 kW @ 0 °C, 0.95 kW @ 10 °C, 1 kW @ 20 °C | ||||||||||||||
Heating or Cooling Capability | Both | ||||||||||||||
Working Temp Range (°C) | -38 … +100 | ||||||||||||||
Pump Capacity Flow Rate (l/min) | 8…27 | ||||||||||||||
Pump Capacity Flow Pressure (psi) | 1.5…10.2 | ||||||||||||||
External Devices | Remote Control | ||||||||||||||
Dimensions W x L x H (in) | 17.7 x 25.2 x 37.4 | ||||||||||||||
Fluid Type | Silicone, Water, Other | ||||||||||||||
Weight (lbs) | 163.1 | ||||||||||||||
Power Options | 230 V / 50 – 60 Hz |
Downloads |
Manual For CORIO CP |
Manual For Refrigerated Baths |
Data Sheet for CORIO CP-1001F |
Name | SKU | Price | Buy |
---|---|---|---|
Julabo, Refrigerated Circulator, CORIO™ CP-1001F - Power Options: 230 V / 50 - 60 Hz | JB-9013708.33 | $15,358.00 |
